Air purifier mod. orange

AIR PURIFIER mod. ORANGE

AIR PURIFIER mod. ORANGE

WALLIE ®

ENVIRONMENTAL MULTIFILTER WITH

ABSOLUTE FILTRATION

ORANGE TYPE

Suitable for:

  • civil environments
  • offices
  • confined zones
  • laboratories

Viruses and bacteria are transported by aerosol particles that can remain suspended in the air, such as PM10, PM5 particulates, gas and more.



From our thirty years of experience in air filtration, we have created the first industrial-derived environmental multifilter, which purifies the air environment by passing through different filter stages and lastly through an industrial HEPA absolute filter.

Why do we specify industrial derivation? Because the filtration speed, the filtering surfaces, the air flow rates are correctly sized according to the canons of industrial filtration.

Our WALLIE multifilter is able to retain those particles with an HEPA absolute final filter having H14 efficiency, 99.995% overall MMPS.

TECHNICAL FEATURES:

  • Structure made of painted steel, swivel wheels, protection nets
  • Easy replacement of filters, through the cover they can be removed from above
  • Filters commonly available on the market
  • Some filters are washable.
  • High head centrifugal fan directly coupled to an electric motor with inverter adjustable by potentiometer.
  • Power switch
  • Hour meter
  • Standard RAL painting chosen between two colors: textured white or textured black (for different RAL, the price will be quoted separately)
  • Final dimensions: 70 x 55 x 80 h cm
  • Recommended local area: approx. 50 sq m



Filters:

TypologyNr. 5 flat

filters

200 g/m2



Nr. 1

corrugated

filter





Nr. 1Active

carbon

filter



Nr. 1 High

efficiency

filter





Nr. 1 High

efficiency

filter





Nr. 1 Absolute

high efficiency

HEPA

filter

EfficiencyG499%950 mg/gM5F7H14
ClassEN 779Particles

20 μm



Iodine

(AWWA

B600)

EN 779EN 779EN 1877
Filtering surface4.500 cm24.500 cm2961 cm2961 cm225.000 cm2





Fan technical data:

Type

Power





Voltage



PhaseAMP.FrequencyAir flow
WALLIE

ORANGE

0,17 Kw220 V1F1,650 Hz1.000 mc/h max



OPTIONAL:

Germicidal UV lamp before the absolute filter

Our offices are at your disposal for further information.



AIRCONTROL ITALY SRL Via Pontarola 62/E Campodarsego – Padova / Tel. 049/9202327-291 / info@aircontrolitaly.it
